IP65 IK08 LED Street Light Manufacturer Customized Watt Streetlight 30W 50W 100W 150W 200W LED Street Light
BH-2102-50W
1
China
● 20-240w，Annual sales abroad are more than 10,000 sets
● Photocell/ Intelligent contol depend on you need，4KV is the basic standard
● Lumileds 3030 chips,130lm/w
● Professional road lighting distribution,70*145°
● All IES test reports can be provided
● Photocell/ Intelligent contol depend on you need，4KV is the basic standard
● Lumileds 3030 chips,130lm/w
● Professional road lighting distribution,70*145°
● All IES test reports can be provided
Quantity
IP65 IK08 LED STREET LIGHT 30W 50W 100W 150W 200W
30W 50W 100W 150W 200W 240W VIEWS
PARAMETERS(china 50w led street light manufacturers)
LAMP SIZE(china 50w led street light manufacturers)
IP65 WATERPROOF TEST(china 50w led street light manufacturers)
WORKSHOP PRODUCTION (china 50w led street light manufacturers)
HOW TO INSTALLATION?(china 50w led street light manufacturers)
30W 50W 100W 150W 200W 240W VIEWS
FEATURE(china 50w led street light manufacturers)
1) Super High Performance Price Ratio:
Higher efficacy LED by Lumileds
China famous driver brand SOSEN,MOSO and INVENTRONICS
More convenient for installation and maintenance
2) Multiple Configurations Optional:
4KV is the basic standard,10KV SPD is optional
Photocell,timer dimming,DALI,0-10V dimming is optional
Intelligent control system with NEMA interface is optional
3) Wider Application:
BH21 series LED street light will provide the better
Lumen output,the better stability and very long lifetime.
Provide 5 years warranty for whole fixture.
It can be applied to streets, roads, highways, squares, parks and parking lots.
Higher efficacy LED by Lumileds
China famous driver brand SOSEN,MOSO and INVENTRONICS
More convenient for installation and maintenance
2) Multiple Configurations Optional:
4KV is the basic standard,10KV SPD is optional
Photocell,timer dimming,DALI,0-10V dimming is optional
Intelligent control system with NEMA interface is optional
3) Wider Application:
BH21 series LED street light will provide the better
Lumen output,the better stability and very long lifetime.
Provide 5 years warranty for whole fixture.
It can be applied to streets, roads, highways, squares, parks and parking lots.
PARAMETERS(china 50w led street light manufacturers)
| Model | BH-2102-50W |
| Nominal Power | 40W-60W |
| Led source | Philips 3030 |
| Power Factor | >0.95 |
| Lumen | >120Lm/W |
| Input Voltage | 100-277VAC,50/60Hz |
| Power Factor | >0.95 |
| Dimensions | 476*194*74mm |
| Light Distribution | 70*145° |
| CCT | 2700-6500K |
| CRI | Ra>70 /80 |
| Protection Grade | IP65,IK08 |
| Electrical Protection | CLASS I or CLASS II |
| THD | <15% |
| Housing | Die-casting Aluminum |
| Qty/Carton | 5PCS |
| G.W/Carton | 9.3kgs |
| Package Size | 550*505*230mm |
LAMP SIZE(china 50w led street light manufacturers)
IP65 WATERPROOF TEST(china 50w led street light manufacturers)
WORKSHOP PRODUCTION (china 50w led street light manufacturers)
HOW TO INSTALLATION?(china 50w led street light manufacturers)
