Outdoor IP65 Waterproof Led Flood Light with remote rgb led module Sport Stadium Lighting
BH-MZ11-RGB
1
● R:620 , G:540 , B: 450
● Modularization pluggable technology, easily installation
● High Power Factor＞0.9,Low THD Driver
● Excellent optics design,greatly improve the light utilization and evenness
● Single damage does not affect the other particle current
● Dust-proof and waterproof,IP65
● Easy replacement of old lights，Very small easy for shipping
● Modularization pluggable technology, easily installation
● High Power Factor＞0.9,Low THD Driver
● Excellent optics design,greatly improve the light utilization and evenness
● Single damage does not affect the other particle current
● Dust-proof and waterproof,IP65
● Easy replacement of old lights，Very small easy for shipping
Quantity
rgb led module FLOOD LIGHT
rgb led module FEATURE
● Using high quality SMD3030 chips
● Modularization pluggable technology, easily installation
● High Power Factor＞0.9,Low THD Driver
● Excellent optics design,greatly improve the light utilization and evenness
● Single damage does not affect the other particle current
● Dust-proof and waterproof,IP65
● Easy replacement of old lights,Very small easy for shipping
● Modularization pluggable technology, easily installation
● High Power Factor＞0.9,Low THD Driver
● Excellent optics design,greatly improve the light utilization and evenness
● Single damage does not affect the other particle current
● Dust-proof and waterproof,IP65
● Easy replacement of old lights,Very small easy for shipping
rgb led module PARAMETERS
| Model | BH-MZ11-RGB |
| Nominal Power | 45W |
| Led source | SMD 3030 /2835 |
| Chip Qty | 84Leds |
| CCT | RGB |
| Dimensions | 298*71*45mm |
| Light Distribution | 15°/40°/60°/90°/30*70°/49*21°/136*78° |
| Material | Aluminum+PC |
| Voltage | DC24V 2.25A |
| CCT | 2700-5700K |
| Power Factory | >0.9 |
| Protection Grade | IP65 |
| Single weight | 0.72kg |
| Finish | Sliver |
| Warranty | 3/5years |
| Qty/Carton | 20PCS |
| Package Size | 675*375*190mm |
rgb led module LAMP SIZE
rgb led module COMPANY WATERPROOF TEST
For street light，For tunnel light，For high bay light，For stadium light，For garden light，For toll station
PACKING:
20pcs in 1 carton,1 layer for 10pcs,total for 2 layers
NO | Model | Power | N.W | Qty/Ctn | G.W | Outer Carton |
1 | BH-DL04-L48 | 40-50W | 0.7kg | 20 | 15kg | 675*375*190mm |
20pcs in 1 carton,1 layer for 10pcs,total for 2 layers
